Seco 74034555 Minimaster™ Milling Tip Insert, ANSI Code: MM12-0.472-CR10-MD05 T60M, MM12 Milling Tip Style, Concave Radius Milling Tip, Solid Carbide, 1 mm Corner Radius, Manufacturer's Grade: T60M, 2 Flutes
SECO 74034555
$114.00
/ Order multiples of 2 EA
Out of Stock
- Finish/Coating: PVD-TiAlN+TiN Coated
- Series: Minimaster
- Milling Tip Style: MM12
- Milling Tip Type: Concave Radius
- Material: Solid Carbide
- Cutting Diameter - Decimal: 0.4720 in
- Cutting Diameter - Metric: 12 mm
- Manufacturer's Grade: T60M
- Depth of Cut: 0.4160 in
- Capacity: 1/4 in
- Chamfer Angle: 0 Degree
- Chipbreaker: MD05
- Coating: Coated; TiAlN/TiN
- Coating Process: PVD
- Corner Radius: 1.000 mm
- Corner Radius - Metric: 1 mm
- Geometry: MD05
- Helix Angle: 0 Degree
- Included Angle: 90 Degree
- Lead Angle: 0 Degree
- Manufacturer Grade: T60M
- Maximum Depth of Cut - Metric: 10.6 mm
- Milling Tip Full Description: Concave Radius
- Number of Flutes: 2
- Part Number: 34555
For milling in soft and medium hard steel
Seco Milling Tip Insert | Series: Minimaster | MM12 Milling Tip | Concave Radius Milling Tip | 12 mm Diameter Cutting | 10.6 mm Maximum Depth of Cut | 2 Flutes | MD05 Geometry | 1 mm Corner Radius | Manufacturer's Grade: T60M | ANSI Code: MM12-0.472-CR10-MD05 T60M | ISO Code: MM12-12010-CR10-MD05 T60M | Solid Carbide | PVD-TiAlN+TiN Coated
