Seco 00084297 Minimaster™ Milling Tip Insert, ANSI Code: MM16-0.750-C90-M06 T60M, MM16 Milling Tip Style, Center Drill Milling Tip, Solid Carbide, 0.421 in Corner Radius, Manufacturer's Grade: T60M, 2 Flutes
SECO 00084297
$181.00
/ EA
Out of Stock
- Finish/Coating: PVD-TiAlN+TiN Coated
- Series: Minimaster
- Milling Tip Style: MM16
- Milling Tip Type: Center Drill
- Material: Solid Carbide
- Cutting Diameter - Decimal: 0.7500 in
- Cutting Diameter - Metric: 19.1 mm
- Material Grade: C5
- Manufacturer's Grade: T60M
- Depth of Cut: 0.3780 in
- Chamfer Angle: 6 Degree
- Chipbreaker: M06
- Coating: Coated; TiAlN/TiN
- Coating Process: PVD
- Corner Radius: 0.421 in
- Geometry: M06
- Included Angle: 90 deg
- Lead Angle: -10 Degree
- Manufacturer Grade: T60M
- Maximum Depth of Cut: 9.6 in
- Milling Tip Full Description: Center Drilling
- Number of Flutes: 2
- Part Number: 84297
HEAD MILL 0.7500MM16-0.750-C90-M06
