Seco 02590775 Perfomax™ SD542 Indexable Insert Drill, 80 mm Drill, ABS 50 Modular Connection, 46 mm Dia Shank, 2.5XD Drill Depth by Dia Ratio, SPGX/SCGX Insert, 200 mm D Max Drill
- Shank Diameter - Metric: 46 mm
- Modular Connection Size: ABS 50
- Drill Depth by Diameter Ratio: 2.5XD
- Coolant Through: Yes
- Diameter - Metric: 80 mm
- Flute Length: 210 in
- Flute Length - Metric: 210
- Maximum Drill Depth - Metric: 200 mm
- Number of Drill Inserts: 4
- Shank Length - Metric: 43 mm
- Shank Type: Modular Connection
Perfomax™ is a long standing, proven range of indexable insert drills that offers an economical solution when it comes to productively drilling holes. Reliable and trustworthy, the strong, square inserts each offer four cutting edges. They can be used with most modern insert grades and coatings. The drill body design features a unique chip flute design, through coolant holes on all sizes and a low friction coating to optimize chip evacuation. The Perfomax™ drill body design is strong and sturdy, capable of handling the highest productivity and offers strong performance in unstable applications.
- Effective chip control for long chipping ductile materials
- Fast and efficient chip evacuation
- Higher cutting parameters for increased drilling output
- Longer tool life gives reduced tool cost
- Exceptional process predictability and reliability
- Better hole tolerance
Seco Indexable Insert Drill | Series: Perfomax SD542 | 80 mm Drill | 46 mm Shank Diameter | 43 mm Shank Length | Modular Connection Shank | ABS 50 Modular Connection Size | SPGX/SCGX Insert | 200 mm Maximum Drill Depth | 80 mm Diameter | 2.5XD Drill Depth by Diameter Ratio | 4 Drill Inserts | Insert Compatibility: SPGX12T3-C1 Center | SCGX120408.. Peripheral | 210 mm Flute Length | Yes Through Coolant
